Product Overview
Brand: bekelan
Color: Reducer Hose
Features:
- 【SIZE & PACKAGE】Small-end ID: 4 inches; large-end ID: 5 inches; overall length: 3 inches; wall: 1/5 inch (5mm). Includes 1 reducer coupler and 2 stainless clamps. Verify both mating pipe ODs.
- 【HIGH TEMP & PRESSURE】Operating temperature: -76°F to 500°F (-60°C to 260°C). Working pressure: 43.5-150 PSI; burst pressure: 290 PSI (2 MPa), for demanding intake and intercooler connections.
- 【4-PLY REINFORCED SILICONE】Silicone construction with 4-ply polyester reinforcement provides strength, flexibility and pressure resistance. The 5mm heavy-duty wall helps the reducer maintain shape under load.
- 【REDUCER APPLICATIONS】4 to 5 Inch Silicone Coupler for compatible turbo, intercooler, charge-pipe and air-intake piping. The 3-inch-long reducer connects a 4-inch OD pipe to a 5-inch OD pipe while allowing flexible alignment.
- 【MEDIA & INSTALLATION】Compatible with air, water, coolant, antifreeze, steam and weak acid/alkali where specifications are suitable. Not for fuel or oil. Confirm both pipe sizes, pressure, temperature and media before use.
Details: Bekelan High-Temp Silicone Reducer Hose Coupler is designed to connect two different pipe sizes in compatible automotive turbo, intercooler, charge-pipe and air-intake systems, as well as marine and industrial applications. PRODUCT SPECIFICATIONS Small-End Inner Diameter (ID): 4 inches Large-End Inner Diameter (ID): 5 inches Small-End Outer Diameter (OD): 4.4 inches Large-End Outer Diameter (OD): 5.4 inches Overall Length: 3 inches Wall Thickness: 1/5 inch (5mm) Material: Silicone + Polyester Reinforcement: 4-Ply Polyester Structure: 9-Layer Working Pressure: 0.3-1 MPa (43.5-150 PSI) Burst Pressure: 2 MPa (290 PSI) Temperature Range: -76°F to 500°F (-60°C to 260°C) Package: 1 × Silicone Reducer Coupler + 2 × Stainless Clamps HIGH-TEMP, HIGH-PRESSURE CONSTRUCTION The reinforced silicone construction combines a 5mm wall with 4-ply polyester reinforcement for strength, flexibility and pressure resistance. It is designed to maintain its shape while accommodating minor alignment and vibration between connected pipes. INTAKE, INTERCOOLER & TURBO PIPING Use as a 4-inch to 5-inch ID silicone reducer coupler for compatible intercooler piping, turbo charge piping and air-intake connections. The 3-inch-long reducer is designed to connect a 4-inch OD pipe to a 5-inch OD pipe. COMPATIBLE MEDIA Suitable for compatible air, water, coolant, antifreeze, steam and weak acid/alkali applications within the stated temperature and pressure limits. IMPORTANT Not suitable for fuel or oil transfer. Verify both mating pipe outside diameters, operating temperature, pressure and media compatibility before installation. Tighten the included clamps appropriately for the application.
